ACO Brickslot RainDrain Slot Drain Channel 1m x 118mm x 173mm - B125

Code:

ACO-47002

Brand:

ACO

Made from Vienite, ACO's high-strength recycled polymer concrete material, this Brickslot RainDrain slot drain channel has been created to deliver efficient water management as part of a subtle and sleek slot drainage channel system. The system is suited for domestic black pav... Read More

View full product details

View questions about this product

There are other items you may need to complete your project, please make your selections below:

Corner Unit and Vertical Outlet

Sump Basket Unit

End Cap

£66.60 Incl. VAT

Earn points

Est. Delivery: 1-2 Working Days

Shipping costs displayed in basket.

For delivery Wednesday, Jan 1st - order in:

days hrs mins secs

Subject to stock availability, if products on a 24 hours service are ordered alongside products NOT on a 24 hours service, this may delay your whole order.

View Transport Policy

View full product details

View questions about this product

Create a wishlist

Brian Mckinlay

Description

This channel includes an offset slotted grating and a slender 10mm inlet slot. Its B125 weight load class rating makes it ideal for areas with light vehicular traffic, such as private car parks and driveways, and perfect for domestic block paving applications up to and including 60mm.

Features & Benefits: ACO Brickslot RainDrain Slot Drain Channel 1m x 118mm x 173mm - B125

Features an offset slotted grating with a slim 10mm inlet slot
Designed to deliver effective water management for domestic black paved surfaces
Quick and easy to install, made from high-strength recycled polymer concrete
B125 weight load class rating ideal for light vehicular traffic
The shape helps to anchor the channel into the surrounding concrete
Knock-out sections for connecting a 110mm pipe
1000mm x 118mm x 173mm

Quick and easy to install, this channel connects firmly via its ingenious interlocking design. With knock-out sections which ensure a complete connection for a 110mm uPVC pipe, its shape fastens it into the surrounding concrete to provide a secure and stable installation.

Standards & Certification

British/European Standards: BS EN 1433: 2002
Certifications: UKCA and CE marked

Please note:

This slot channel is not suitable for public car parks with high levels of vehicular traffic.

Specification

Dimensions

Length 1m Depth 173mm Width 118mm

Details

Material Concrete Product Type Channel Base and Grate Features Slot Drain Range RainDrain

Load Rating B125

Downloads

Installation Guide

Questions & Answers

Question:

I'm interested in purchasing around 50m of the ACO RainDrain Brickslot B 125. Could you tell me how a 90 degree corner can be achieved?

Answer:

You would need to cut each channel at a 45 degree angle, and miter them together.

Question:

Can these be cut to make smaller lengths?

Answer:

These channels can be cut to size.

Question:

Are there internal and external corners available?

Answer:

This range does not have corners. In order to create a corner, you would need to cut a 45 degree angle on both of the channels making up the corner section.

Question:

How do we deal with removing dirt and leaves from an ACO Brickslot RainDrain slot drain channel as they will drop through the slot?

Answer:

You would need to install either product 47004 or 47003. Both have a lift out tray which would give you access for unblocking from the ACO Brickslot RainDrain slot drain channel. The sump unit would also collect silt.
