Home Building Drainage Floor Gullies Domestic Floor Gullies Harmer Aluminium Horizontal Drain White Clamp & Pebble Cap 200mm x 200mm - Tile Floor

Harmer Aluminium Horizontal Drain White Clamp & Pebble Cap 200mm x 200mm - Tile Floor

Code:
AHS/WH/T20
Brand:
Harmer

This aluminium horizontal shower drain from Harmer features a 200mm x 200mm tile frame and a white polyester powder-coated aluminium clamp with a pebble drain cap which is easy to remove so it can be cleaned, replaced or provide access to the removable 50mm foul air trap below... Read More

View full product details
View questions about this product
£170.00 Incl. VAT
Earn points

SUPER Rewards Earn points and build more across our SUPERSTORES!

Find out more
Oops! Please select from the options
Est. Delivery: 3-5 Working Days
Shipping costs displayed in basket.
We can let you know when this product is back in stock.

This product is proving to be very popular and has unfortunately sold out.

Enter your email below and we'll notify you as soon as this product is back in stock:

For delivery Monday, Nov 25th - order in:
days hrs mins secs
Subject to stock availability, if products on a 24 hours service are ordered alongside products NOT on a 24 hours service, this may delay your whole order.
View Transport Policy

All delivery charges are included in the final shopping basket and are dependent on the products Scottish Highlands & the Islands where additional shipping charges will apply.

Please note that not all products will incur an additional delivery charge to the Scottish Highlands & the Islands – this is based on the costs from the manufacturer, distributor or courier providing shipping on our behalf. If your delivery address is in the Scottish Highlands and Islands, a member of our helpline team will contact you prior to processing your order should an additional delivery charge apply.

While we make every effort to ensure orders are delivered by the date required, we cannot guarantee availability from the manufacturer or the manufacturer's delivery schedules.

Any variation to web delivery date given will be advised to you by email or telephone. If we are unable to make delivery because access is not possible, we reserve the right to make a failed delivery charge.

View full product details
View questions about this product
Create a wishlist

"Cheaper than rest and quick"

Mr Stephen Thomson
Description Specification Downloads Q&A

Description

This aluminium horizontal shower drain from Harmer features a 200mm x 200mm tile frame and a white polyester powder-coated aluminium clamp with a pebble drain cap which is easy to remove so it can be cleaned, replaced or provide access to the removable 50mm foul air trap below.

Compatible with 56mm cast iron, PVC and HDPE pipes, this Horizontal Harmer shower drain's body has an integral fall in the sump to eradicate silt collection. Lightweight yet strong and durable due to its LM6 aluminium alloy structure and a polyester powder coating for heightened protection, it can deliver a flow rate of up to 0.8 litres per second. Suitable for timber and concrete floor applications, it is completed with an attractive PPC aluminium clamp which is ideal for tiled flooring.

Features & Benefits: Harmer Aluminium Horizontal Drain White Clamp & Pebble Cap 200mm x 200mm - Tile Floor

  • Ideal for tiled flooring
  • Suitable for timber and concrete floor applications
  • Lightweight yet strong and durable
  • 200mm x 200mm tile frame
  • Manufactured from LM6 aluminium alloy with polyester powder coating
  • K3 Load Class to BS EN 1253
  • 0.8 litres per second flow rate
  • Pebble style cap

Manufactured from 100% recycled aluminium, this shower drain's body can be recycled once again at the end of its life cycle. The LM6 aluminium alloy ensures it can be used in marine environments and general atmospheric conditions, displaying high resistance to corrosion. Specially designed to meet the requirements of British and European standard BS EN 1253 for loading, flow performance and design, this Harmer aluminium shower drain can withstand up to 300kg of vertical loading.

Harmer Aluminium Horizontal Drain Contents

  • 1 x pebble drain cap
  • 1 x 200mm x 200mm tile frame
  • 1 x white PPC aluminium clamp
  • Clamp screws
  • 1 x 50mm foul air trap (FAT)
  • 1 x two-inch outlet horizontal drain body
  • Stainless steel screws

Standards & Certification

  • Meets the requirements of British and European standard BS EN 1253 for design, flow performance and loading

Please note:

  • There is an option to order security fixings for drain caps in areas where the cap may otherwise be tampered with. Contact us for more information.

Details

Material Aluminium Product Type Shower Drain Weight Class K3 Floor Type Tiled Flooring
Type Domestic Application Concrete
Floors
Timber
